- Dimensions (HWD): 270 x 390 x 135 mm (10.6 x 15.3 x 5.3 in)
- Weight: 4kg (8.8 lb)
- Operating temperature: -25°C to 45°C (-13°F to 113°F)
- Storage Temperature: -25°C to 70°C (-13°F to 158°F)
- Feed-in type(AC Distribution Board): Split phase (L1, L2, N)
- Input(AC Distribution Board): Max 50A, 120/240V, 60Hz
- Maximum Input Short-circuit Current(AC Distribution Board): 10kA
- Output(AC Distribution Board): Max 30A for each branch circuit
- AC Circuit(AC Distribution Board): 12 branch circuits breaker stabs
- Strain Relief knockout(AC Distribution Board): 2x3/4 inch, 1x1 inch
- Input(AC Distribution Board): Max 100A, 13/26V⎓
- Output(AC Distribution Board): F1-F13: rated up to 30A, continuous operating current <20A, 14F16: rated up to 50A, continuous operating current <33A
-
Warranty: 5 Years
